Gold Plated Battery Terminal for High‑Current Wiring

Battery Terminals for high current wiring

Specification

Item Number		Description & Dimensions
BT-2700		Screw-In Type Available in positive & Negative Terminal Models One 4AWG & Two 8AWG connection Weight: P:100g; N:103g Dimension: 50.5 X 43.5 X 16(mm)
BT-2900		Available in positive & Negative Terminal Models One 0AWG & One 4AWG; Two 8AWG connection Weight: P:170g; N:172g Dimension: 53 X 48.6 X 21.6(mm)
BT-3000		Screw-In Type Available in positive & Negative Terminal Models One 0AWG & One 4AWG; Two 8AWG connection Weight: P:239g; N:245g Dimension: 61 X 60 X 25.5(mm)
CBT-0710A		Available in positive & Negative Terminal Models One 4AWG & Two 8AWG connection; 4 Allen screw Weight: P:90.7g; N:93g Dimension: 50 X 47 X 16(mm)
CBTL-0710A		Available in positive & Negative Terminal Models One 0AWG & Two 8AWG connection; 4 Allen screw Weight: P:125.7g; N:131.3g Dimension: 56 X 47 X 20(mm)

Product Packaging

• Standard Package: 1,000 PCS per polybag.

Hansor gold plated battery terminal is designed for reliable high-current connections in automotive, audio, and industrial wiring systems. Constructed from solid brass with gold plating, it ensures low electrical resistance, excellent conductivity, and superior corrosion resistance. The terminals support both positive and negative battery connections with multiple wire gauges for flexible installation.

Key Features

• Gold Plated Brass Contact: Significantly reduces resistance and improves current flow for high-performance setups.
• Secure Installation: Precision Allen screws hold wires firmly to ensure stable mechanical and electrical connections under vibration.
• Multi-Wire Support: Versatile output configuration allows connecting one 4AWG and two 8AWG wires safely.
• Durable & Corrosion-Resistant: Engineered to withstand harsh automotive, marine, and industrial environments.
• Compact & Versatile Design: Streamlined profile allows for easy integration into crowded battery compartments.

Applications

The Hansor gold plated battery terminal is suitable for:

• Automotive battery connections and charging systems.
• Aftermarket car and marine audio power distribution.
• High-current wiring harnesses for specialized vehicles.
• Industrial power systems requiring reliable, low-resistance terminal contacts.

Why Choose Hansor

Hansor has decades of experience producing electrical components for automotive and industrial use. Our gold plated battery terminal products combine high-quality materials, precise machining, and reliable design to ensure secure connections. We support OEMs, installers, and engineers with wiring solutions that balance performance and long-term safety.
